Overview
Main Features
1. Compact size and easy maintenance
2. Gas usage monitoring and dual channel layout
3. Full electronic measurement
4. Various intelligent applications
5. Muitiple communication modes
6. Accuracy remains unchanged for 10 years
7. Real-time temperature & pressurе compensation
8. Normal measurement when abnormal power supply
Technical Parameters
|
Parameters |
Unit |
G6 |
G10 |
|
|
Maximum Flowrate (Qmax) |
m³/h |
10 |
16 |
|
|
Minimum Flowrate (Qmin) |
m³/h |
0.006 |
0.1 |
|
|
Start Flowrate (Qstart) |
m³/h |
0.008 |
0.013 |
|
|
MPE |
Qmin≤Q<0.1 Qmax |
% |
±3.0 |
|
|
0.1 Qmax≤Q≤Qmax |
±1.5 |
|||
|
Maximum Working Pressure (Pmax) |
kPa |
≤50 |
||
|
Maximum Pressure Absorption |
Pa |
≤250 |
≤375 |
|
|
Gas Temperature Range (tg) |
℃ |
-25 to +55 |
||
|
Storage Temperature |
℃ |
-30 to +60 |
||
|
Humidity |
% |
≤95 |
||
|
Battery Information |
V |
Main unit: 7.2 V lithium battery Measurement: 3.6 V lithium battery |
||
|
Thread |
Inch |
G1¼" |
||
|
Connection Centers |
mm |
150 |
||
|
Protection Rating |
Class |
IP65 |
||
|
Overall Dimensions |
mm |
270*137*173 |
||
|
Medium |
/ |
NG |
||
|
Mechanical Environment |
Class |
M1 |
||
|
Electronical Environment |
Class |
E2 |
||
|
Communication |
/ |
GRPS/4G/NB-loT/Customized |
||
|
Case Material |
/ |
Steel |
||
Dimension
Why Choose Us
1. Manufacturing Strength
Our production lines combine precision engineering with intelligent automation - ensuring consistent quality across standard and custom orders alike. The outcome: faster turnaround, high build standards, and delivery you can depend on.
2. Global Certifications
Our meters are certified to key international standards - MID, ATEX, ISO 9001, ISO 14001, ISO 45001, and IPMS. These aren't just badges; they reflect our commitment to safety, quality, and environmental responsibility across every product line.
3. Tailored Solutions
We go beyond off‑the‑shelf products. Whether it's custom branding or tailored communication interfaces, we collaborate with you to build solutions that match your exact requirements - production‑ready and aligned with your brand identity.
4. End‑to‑End Quality Control
Our quality process begins with raw material verification and continues through every stage of production - with in‑process inspections and final testing before shipment. Full traceability and strict quality checkpoints ensure every meter performs reliably in real‑world conditions.
