Overview
Main Features
1. Compact size and easy maintenance
2. Gas usage monitoring and dual channel layout
3. Full electronic measurement
4. Various intelligent applications
5. Muitiple communication modes
6. Accuracy remains unchanged for 10 years
7. Real-time temperature & pressurе compensation
8. Normal measurement when abnormal power supply
Technical Parameters
|
Parameters |
Unit |
G6 |
G10 |
|
|
Maximum Flowrate (Qmax) |
m³/h |
10 |
16 |
|
|
Minimum Flowrate (Qmin) |
m³/h |
0.006 |
0.1 |
|
|
Start Flowrate (Qstart) |
m³/h |
0.008 |
0.013 |
|
|
MPE |
Qmin≤Q<0.1 Qmax |
% |
±3.0 |
|
|
0.1 Qmax≤Q≤Qmax |
±1.5 |
|||
|
Maximum Working Pressure (Pmax) |
kPa |
≤50 |
||
|
Maximum Pressure Absorption |
Pa |
≤250 |
≤375 |
|
|
Gas Temperature Range (tg) |
℃ |
-25 to +55 |
||
|
Storage Temperature |
℃ |
-30 to +60 |
||
|
Humidity |
% |
≤95 |
||
|
Battery Information |
V |
Main unit: 7.2 V lithium battery Measurement: 3.6 V lithium battery |
||
|
Thread |
Inch |
G1¼" |
||
|
Connection Centers |
mm |
150 |
||
|
Protection Rating |
Class |
IP65 |
||
|
Overall Dimensions |
mm |
270*137*173 |
||
|
Medium |
/ |
NG |
||
|
Mechanical Environment |
Class |
M1 |
||
|
Electronical Environment |
Class |
E2 |
||
|
Communication |
/ |
GRPS/4G/NB-loT/Customized |
||
|
Case Material |
/ |
Steel |
||
Dimension
Why Choose Us
1. Industry Heritage
VIEWSHINE has spent over two decades advancing ultrasonic measurement technology, delivering high‑performance gas meters, water meters, and IoT‑enabled metering platforms to gas utilities, water utilities, and industrial customers across the globe. Our participation in shaping China's national metering standards reflects our technical depth and industry influence.
2. Skilled Professionals
Our R&D and QC teams are specialists in IoT‑ready gas meters, ultrasonic metering, and smart gas solutions - ensuring every product complies with international standards for OEM partners, utility buyers, and large‑scale procurement programs. Consistent quality and certifiable performance are built into every meter.
3. Exceptional Customer Care
We support our customers at every step - from initial consultation and system design to deployment, training, and ongoing maintenance. Our team works closely with distributors, system integrators, and utility partners to ensure your metering infrastructure delivers reliable data and long‑term value over its entire lifecycle.
4. Direct‑from‑Source Pricing
As a direct manufacturer and OEM supplier, we eliminate intermediaries to offer competitive, transparent pricing on ultrasonic gas meters, smart water meters, and IoT metering solutions. No hidden costs - just high‑quality metering at factory‑direct prices, backed by full technical support.
Hot Tags: Commercial Gas Meter With Remote Control, China Commercial Gas Meter With Remote Control manufacturers, suppliers, factory
