Overview
Engineered for space-constrained installations, the U-GR3 smart ultrasonic gas meter delivers accurate measurement across a wide flow range of 0.016 to 10 m³/h. Its solid-state design ensures long-term stability, while integrated IoT connectivity enables real-time leak detection, pressure anomaly alerts, and tamper notifications. When abnormal conditions are detected, the built-in valve automatically shuts off and sends instant alarms to the cloud platform for immediate response.
Main Features
1. Built-in shut-off valve for automated safety response
2. Meter removal platform for easy maintenance
3. Gas leak monitoring with instant alerts
4. Wide measuring range (0.016–10 m³/h)
5. High accuracy with temperature & pressure compensation
6. Long-term data storage for usage tracking
Technical Parameters
|
Parameters |
Unit |
G1.6 |
G2.5 |
G4.0 |
G6.0 |
||||
|
Maximum Flowrate (Qmax) |
m³/h |
2.5 |
4.0 |
6.0 |
10.0 |
||||
|
Minimum Flowrate (Qmin) |
m³/h |
0.016 |
0.025 |
0.040 |
0.060 |
||||
|
Start Flowrate (Qstart) |
m³/h |
0.003 |
0.004 |
||||||
|
MPE |
Qmin ≤ Q < 0.1 Qmax |
% |
± 3.0 |
||||||
|
0.1 Qmax ≤ Q ≤ Qmax |
± 1.5 |
||||||||
|
Maximum Working Pressure (Pmax) |
kPa |
15 |
|||||||
|
Maximum Pressure Absorption |
Pa |
≤200 |
≤250 |
||||||
|
Gas Temperature Range (tg) |
℃ |
-25 to +55 |
|||||||
|
Storage Temperature |
℃ |
-30 to +60 |
|||||||
|
Humidity |
% |
≤95 |
|||||||
|
Battery Information |
V |
Measurement: 3.6 V lithium battery |
|||||||
|
Thread |
Inch |
G3/4", G1" |
|||||||
|
Protection Grade |
/ |
IP65 |
|||||||
|
Overall Dimensions |
mm |
252 * 100 * 98 |
|||||||
|
Medium |
/ |
NG |
|||||||
|
Mechanical Environment |
/ |
M1 |
|||||||
|
Electronic Environment |
/ |
E2 |
|||||||
|
Communication |
/ |
GPRS / LoRaWAN / 4G |
|||||||
|
Case Material |
/ |
Steel |
|||||||
Dimension
