Overview
Built for space‑constrained installations, the U‑GR3 smart ultrasonic gas meter offers accurate, maintenance‑free flow measurement from 0.016 to 10 m³/h. Its compact footprint fits easily into confined areas, while integrated IoT connectivity enables real‑time monitoring for gas leaks, pressure fluctuations, and tamper attempts. When an anomaly is detected, the internal valve closes automatically and instant cloud alerts are triggered - ensuring fast response with no human intervention required.
Main Features
1. Built-in shut-off valve for automated safety response
2. Meter removal platform for easy maintenance
3. Gas leak monitoring with instant alerts
4. Wide measuring range (0.016–10 m³/h)
5. High accuracy with temperature & pressure compensation
6. Long-term data storage for usage tracking
Technical Parameters
|
Parameters |
Unit |
G1.6 |
G2.5 |
G4.0 |
G6.0 |
||||
|
Maximum Flowrate (Qmax) |
m³/h |
2.5 |
4.0 |
6.0 |
10.0 |
||||
|
Minimum Flowrate (Qmin) |
m³/h |
0.016 |
0.025 |
0.040 |
0.060 |
||||
|
Start Flowrate (Qstart) |
m³/h |
0.003 |
0.004 |
||||||
|
MPE |
Qmin ≤ Q < 0.1 Qmax |
% |
± 3.0 |
||||||
|
0.1 Qmax ≤ Q ≤ Qmax |
± 1.5 |
||||||||
|
Maximum Working Pressure (Pmax) |
kPa |
15 |
|||||||
|
Maximum Pressure Absorption |
Pa |
≤200 |
≤250 |
||||||
|
Gas Temperature Range (tg) |
℃ |
-25 to +55 |
|||||||
|
Ambient Temperature (tm) |
℃ |
-30 to +60 |
|||||||
|
Humidity |
% |
≤95 |
|||||||
|
Battery Information |
V |
Measurement: 3.6 V lithium battery |
|||||||
|
Thread |
Inch |
G3/4", G1" |
|||||||
|
Protection Rating |
Class |
IP65 |
|||||||
|
Overall Dimension |
mm |
252 * 100 * 98 |
|||||||
|
Medium |
mm |
NG |
|||||||
|
Mechanical Environment |
Class |
M1 |
|||||||
|
Electronic Environment |
Class |
E2 |
|||||||
|
Communication |
/ |
GPRS / LoRaWAN / 4G |
|||||||
|
Case Material |
/ |
Steel |
|||||||
Dimension
