Main Features
- Compact size
- Easy maintenance
- Gas usage monitoring
- Dual channel layout
- Full electronic measurement
- Various intelligent applications
- Multiple communication modes
- Accuracy remains unchanged for 10 years
- Real-time temperature & pressure compensation
- Normal measurement when abnormal power supply
Technical Parameters
|
Parameters |
Unit |
G6 |
G10 |
|
|
Maximum Flowrate (Qmax) |
m³/h |
10 |
16 |
|
|
Minimum Flowrate (Qmin) |
m³/h |
0.006 |
0.1 |
|
|
Start Flowrate (Qstart) |
m³/h |
0.008 |
0.013 |
|
|
MPE |
Qmin≤Q<0.1Qmax |
% |
±3.0 |
|
|
0.1Qmax≤Q≤Qmax |
±1.5 |
|||
|
Maximum Working Pressure (Pmax) |
kPa |
≤50 |
||
|
Maximum Pressure Absorption |
Pa |
≤250 |
≤375 |
|
|
Gas Temperature Range (tg) |
℃ |
-25 to +55 |
||
|
Storage Temperature |
℃ |
-30 to +60 |
||
|
Humidity |
% |
≤95 |
||
|
Battery Information |
V |
Main unit: 7.2 V lithium battery Measurement: 3.6 V lithium battery |
||
|
Thread |
Inch |
G1¼" |
||
|
Connection Centers |
mm |
150 |
||
|
Protection Grade |
/ |
IP65 |
||
|
Overall Dimensions |
mm |
270*137*173 |
||
|
Medium |
/ |
NG |
||
|
Mechanical Environment |
/ |
M1 |
||
|
Electronical Environment |
/ |
E2 |
||
|
Communication |
/ |
GRPS/4G/NB-loT/Customized |
||
|
Case Material |
/ |
Steel |
||
Dimension
|
A(mm) |
B(mm) |
C(mm) |
D(mm) |
E(inch) |
|
150 |
270 |
137 |
173 |
G1¼" |
