Main Features
- IP68 rated (dust‑tight and fully waterproof)
- U0/D0 installation classification
- WRAS certified (complies with UK water regulations)
- OIML certified
- MID B+D module certified
- Water quality test report supplied
- Supports various communication protocols
- Can be mounted in any orientation
- Flow‑partitioning metering with statistical functions
- Extremely low pressure loss
- Compact footprint with rugged construction
- Wide turndown ratio: R800/R500
- Leak detection and no‑flow‑running prevention
- Data re‑transmission and re‑issuance mechanism
- No moving parts; designed service life over 12 years
- Manufactured from durable, eco‑friendly composite material
- Excellent anti‑interference capability – unaffected by media type or external magnetic fields
Technical Parameters
|
Specifications |
|||||||
|
Standards |
ISO 4064-1:2017;OIML R49:2013 |
||||||
|
Accuracy classs |
Class 2 |
||||||
|
Nominal diameter |
DN |
mm |
15 |
20 |
25 |
15 |
20 |
|
Permanent flow rate |
Q3 |
m³/h |
2.5 |
4 |
6.3 |
2.5 |
4 |
|
Overload flow rate |
Q4 |
m³/h |
3.125 |
5 |
7.875 |
3.125 |
5 |
|
Transitional flow rate |
Q2 |
L/h |
8 |
12.8 |
20.2 |
5 |
8 |
|
Minimum flow rate |
Q1 |
L/h |
5 |
8 |
12.6 |
3.125 |
5 |
|
Measurement range |
R |
Q3/Q1 |
R500 |
R800 |
|||
|
Starting flow |
– |
- |
DN15&DN20: 1.5-2 L/h; DN25: 4-6 L/h |
||||
|
Range for R500, R800 |
Q2/Q1 |
1.6 |
|||||
|
Temperature class (EN and OIML) |
– |
℃ |
T50/T30 |
||||
|
Flow profile sensitivity class (EN) |
– |
– |
U0/D0 |
||||
|
Counter indication range |
– |
m³ |
999999.999 |
||||
|
Scale interval value |
– |
m³ |
0.000001 |
||||
|
Maximum permissible error in the range of Q2 ≤ Q ≤ Q4 |
ε |
% |
0. 1℃<=T<=30℃: ±2%; 30℃ |
||||
|
Maximum permissible error in the range of Q1 ≤ Q < Q2 |
ε |
% |
±5 |
||||
|
Battery |
– |
V |
3.6 |
||||
|
Max battery life |
Years |
12 |
|||||
|
Communication interfaces |
– |
– |
LoRaWAN/NB-IoT/Pulse/wM-Bus |
||||
|
Water pressure class |
(EN) |
bar |
MAP16 |
||||
|
(OIML) |
0.3 to 16 |
||||||
|
Maximum pressure loss |
– |
0.4 |
0.25 |
0.4 |
0.25 |
||
|
Installation orientation |
– |
– |
All Positions |
H |
|||
|
Reverse flow |
– |
– |
Measurable reverse flow |
||||
|
Relative humidity |
% |
≤ 100 |
|||||
|
IP rating |
– |
– |
IP68 |
||||
|
Water meter tube material |
Composite material |
||||||
Dimension
|
DN |
H |
H1 |
L |
L1 |
B |
D |
d |
|
DN15 |
96 |
79.5 |
110/115/130/165 |
47 |
85 |
G 3/4 |
R 1/2 |
|
DN20 |
99 |
80.5 |
110/115/130/190 |
49 |
85 |
G 1 |
R 3/4 |
|
DN25 |
109 |
88 |
150/260 |
60 |
85 |
G1 1/4 |
R 1 |
