Due to factors such as large water supply areas, low accuracy of data reading, long problem detection cycles, inability to trace historical information, and high management costs, the supply and sales gap and operating costs of water companies remain high. The demand for improving the measurement accuracy level of water meters, expanding the range ratio, and improving the measurement characteristics of small flow rates is increasing. With the evolution of digitization, water companies are facing transformational needs in products, technologies, and services.
With the development of new flow sensing and measurement technologies, ultrasonic water meters, as a new generation of intelligent water meters, have attracted more and more attention from water companies.
Based on its many years of experience and expertise in ultrasonic measurement technology, Viewshine has been conducting in-depth research on the application of ultrasonic measurement technology in the water and gas industries, providing customers with mature and reliable products and solutions.
Viewshine Wireless Remote Ultrasonic Cold Water Meter is an electronic water meter that uses ultrasonic measurement technology to measure water volume and is applied to the metering of drinking water and cold water in the water supply network. It provides a worry-free, labor-saving, reliable, convenient, safe, and efficient experience throughout the process from installation, measurement, information transmission to maintenance, helping water companies reduce supply and sales differences and achieve intelligent operation and fine management.
1. Empowered by ultrasonic technology: excellent measurement performance
The Viewshine Wireless Remote Ultrasonic Cold Water Meter measures the flow accurately by detecting the time difference of ultrasonic waves passing through the fluid medium and records, stores, transmits, and reports the measurement information collected by the meter regularly to provide more reliable and accurate water measurement and richer usage data.
2. IoT-enabled: stable meter reading and cloud data
The Viewshine Wireless Remote Ultrasonic Cold Water Meter reports the metering information of the meter regularly through the communication module. Its communication methods can be divided into three types: LoRaWAN Class A, NB-IoT standard, and pulse output. It solves many problems of traditional smart water meter reading and establishes a reliable data transmission between smart water meters and water enterprise IT systems, thus achieving stable meter reading at the meter end and more intelligent management.
3. Internationally recognized: MID certification + OIML certification
The Viewshine Ultrasonic Water Meter U-WR series for civil use passed the high-value and difficult MID and OIML certifications in 2017 and received a conformity certificate and certification report from the internationally authoritative certification body NMi Certin B.V. Taking this opportunity, Viewshine has successfully developed the international market for ultrasonic water meters, and its products are exported overseas.
4. Helps water companies reduce costs and increase efficiency in all aspects.
High measurement accuracy, low start-up flow rate, and wide range ratio - worry-free.
The ultrasonic measurement technology has high measurement accuracy, and the selectable range ratio is R80~R400. The larger the range ratio, the wider the range that can be accurately measured. The minimum detectable flow rate is 2L/h, and the measurement error is small, with excellent measurement performance.
IP68 dustproof and waterproof - stable and reliable
The shell protection level reaches the highest IP68 protection level, and the environmental adaptability is strong. It can still work normally in harsh environments such as long-term immersion and humid environment.
Low installation environment requirements, strong anti-interference ability - simple construction
Using ultrasonic flow measurement technology, it can be installed at multiple angles, and the instrument measurement is not affected, with low pressure loss, high measurement stability, and strong anti-interference ability. The upstream and downstream flow sensitivity is UO & DO, which means that high-precision measurement can be guaranteed without a straight pipe section before and after the meter.
Long service life, stable measurement accuracy - maintenance-free
With innovative design, Viewshine ultrasonic cold water meter is not affected by impurities in the water, with high measurement accuracy and long service life. Within the service life, the meter requires no maintenance, which can greatly reduce the management and operation costs of water companies.
Rich data - providing data support for fine management
The Viewshine Wireless Remote Ultrasonic Cold Water Meter uses ultrasonic high-precision measurement, and its data covers cumulative flow, instantaneous flow, water temperature, as well as alarm events and diagnostic events. Among them, alarm events include backflow, empty pipe, drip, abnormal temperature, and abnormal flow (overflow). When the meter exceeds the preset range, it will send an alarm signal, which can provide early warning and diagnosis for the water supply network.
In the era of big data, rich user data, timely reporting and communication through smart water meters enable remote control at the meter end, meeting various water fee gradient settlement methods, which helps to monitor water loss and conserve water resources. At the same time, data analysis can enhance understanding of user needs and promote service improvement for water enterprises.
